５ Attach the new banding band and the packing, and then reassemble all the removed
parts in reverse order of the procedures above.
[Cautions]
(1) When attaching new packing, peel off the paper liner first, and then apply the packing around the
bundle of both wires and tubes.
(2) When reassembling the removed parts, be sure NOT to pinch any wires.
(3) When attaching the new banding band(s) and the new packing, be sure to the points described
in the figure below.
Make and position the knots of the banding
.
bands diagonnaly
Refer to these figures when attaching the banding band(s)
and the packing for their locations and directions.
Attach the packing and the banding band(s)
referring to the mark on the tube, which is put in
２.
procedure
5-18
