5.3 Gutter configuration and replacement method

5.3.1 Gutter configuration

The gutter and the gutter base are connected and cannot be disassembled.

5.3.2 Replacement method

１ Remove the 2 fastening screws
２ The gutter base comes off.
Gutter
base
Gutter
Gutter base
O-ring 2.2
5-3
Fastening
screws
