Ricoh MP C3004 Field Service Manual page 985

SC No. Type
SC720-25 B
SC720-27 B
SC720-28 B
SC720-30 B
SC720-33 B
SC720-34 B
SC720-35 B
SC720-41 B
Error Name/Error Condition/Major Cause/Solution
Punching Motor Error
Punch Displacement Motor Error
Horizontal Registration Detection Displacement Motor Error
Jogger Motor Error
Positioning Roller Drive Motor Error
Error Condition of -20, -24, -25, -27, -28, -30, -33
• During movement to home, the home position could not be detected
within a predetermined pulse (1st time is jam notification, 2nd time is
SC notification).
• During movement from home, the home position was detected for
longer than a predetermined pulse (1st time is jam notification, 2nd
time is SC notification).
Positioning Transport Motor Error
Motor driver detects an error (DC motor control error) (1st time is jam
notification, 2nd time is SC notification)
Rear End Press Motor Error
• Motor driver detects an error (DC motor control error) (1st time is
jam notification, 2nd time is SC notification)
• During movement to home, the home position could not be detected
within a predetermined time (1st time is jam notification, 2nd time is
SC notification).
• During movement from home, the home position was detected for
longer than a predetermined time (1st time is jam notification, 2nd
time is SC notification).
Release Motor Error
Service Call 700-792
977
