Location
Rear maintenance
Front maintenance
Top maintenance
Related Information
"Physical Specifications" on page 96
■
"Rack and Floor Cutout Dimensions" on page 97
■

Rack and Floor Cutout Dimensions

If you plan to route cables down through the bottom of the rack, cut a rectangular hole in the
floor tile. Locate the hole below the rear portion of the rack, between the two rear casters and
behind the rear inner rails. The suggested hole width is 280 mm (11 inches).
If you want a separate grounding cable, see
Do not create a hole where the rack casters or leveling feet will be placed.
Caution -
Reviewing System Specifications
"Install a Ground Cable (Optional)" on page
Maintenance Access
914 mm 36 in.
914 mm 36 in.
914 mm 36 in.
124.
Preparing the Site 97
