Understanding Expansion Rack Internal Cabling

Single-Phase PDU Cabling

This topic contains tables that list the single-phase cabling from each PDU to the power
supplies configured in each rack. The cables are terminated to PDU-A on the left, and routed to
the right to enter CMA, and are bundled in groups of four.
Table 77, "Single-Phase PDU Cabling for the Expansion Rack (Full Rack)," on page 308
■
Table 78, "Single-Phase PDU Cabling for the Expansion Rack (Half Rack)," on page 309
■
Table 79, "Single-Phase PDU Cabling for the Expansion Rack (Quarter Rack)," on page
■
309
TABLE 77
Rack Unit
U41
U39
U37
U35
U33
U31
U29
U27
U25
U24
U23
U22
U21
U20
U18
U16
U14
U12
U10
U8
U6
U4
U2
U1
308 Oracle SuperCluster T5-8 Owner's Guide • May 2016
Single-Phase PDU Cabling for the Expansion Rack (Full Rack)
PDU-A/PS-00
G5-6
G5-3
G5-0
G4-6
G4-4
G4-2
G3-6
G3-5
G3-3
G3-1
N/A
G2-5
G3-0
G2-4
G2-2
G1-6
G2-0
G1-4
G1-2
G1-0
G0-6
G0-4
G0-2
G0-0
PDU-B/PS-01
G0-0
G0-3
G0-6
G1-0
G1-2
G1-4
G2-0
G2-1
G2-3
G2-5
G3-0
G3-1
G2-6
G3-2
G3-4
G4-0
G3-6
G4-2
G4-4
G4-6
G5-0
G5-2
G5-4
G5-6
Cable Length
2 meters
2 meters
2 meters
2 meters
2 meters
2 meters
2 meters
2 meters
2 meters
2 meters
included
1 meter
2 meters
2 meters
2 meters
2 meters
2 meters
2 meters
2 meters
2 meters
2 meters
2 meters
2 meters
2 meters
