Four-Rack Cabling
Leaf Switch
The following table shows the cable connections for the second spine switch (R2-U1) when
cabling four full racks together.
TABLE 28
Leaf Switch
R2-U32 within Rack 2
R2-U32 to Rack 1
R2-U32 to Rack 3
R2-U32 to Rack 4
R2-U26 within Rack 2
R2-U26 to Rack 1
R2-U26 to Rack 3
R2-U26 to Rack 4
The following table shows the cable connections for the third spine switch (R3-U1) when
cabling four full racks together.
TABLE 29
Leaf Switch
R3-U32 within Rack 3
R3-U32 to Rack 1
268 Oracle SuperCluster T5-8 Owner's Guide • May 2016
Connection
R1-U26-P11B to R4-U1-P10B
Leaf Switch Connections for the Second Rack in a Four-Rack System
Connection
R2-U32-P8A to R2-U1-P3A
R2-U32-P8B to R2-U1-P4A
R2-U32-P11A to R1-U1-P9A
R2-U32-P11B to R1-U1-P10A
R2-U32-P9A to R3-U1-P5A
R2-U32-P9B to R3-U1-P6A
R2-U32-P10A to R4-U1-P7A
R2-U32-P10B to R4-U1-P8A
R2-U26-P8A to R2-U1-P3B
R2-U26-P8B to R2-U1-P4B
R2-U26-P11A to R1-U1-P9B
R2-U26-P11B to R1-U1-P10B
R2-U26-P9A to R3-U1-P5B
R2-U26-P9B to R3-U1-P6B
R2-U26-P10A to R4-U1-P7B
R2-U26-P10B to R4-U1-P8B
Leaf Switch Connections for the Third Rack in a Four-Rack System
Connection
R3-U32-P8A to R3-U1-P3A
R3-U32-P8B to R3-U1-P4A
R3-U32-P10A to R1-U1-P7A
R3-U32-P10B to R1-U1-P8A
Cable Length
Cable Length
5 meters
5 meters
5 meters
5 meters
5 meters
5 meters
5 meters
5 meters
Cable Length
5 meters
5 meters
