PDU Thresholds (Quarter-Populated Racks)
TABLE 11 22kVA Single-Phase PDUs
PDU A PDU B
M1-3 M1-1
M1-2 M1-2
M1-1 M1-3
TABLE 12 24kVA 3-Phase PDUs
PDU A PDU B
M2-3 M1-3
M2-2 M1-2
M2-1 M1-1
M1-3 M2-3
M1-2 M2-2
M1-1 M2-1
PDU Thresholds (Half-Populated Racks)
22kVA Single-Phase PDUs
TABLE 13
PDU A PDU B
M1-3 M1-1
M1-2 M1-2
M1-1 M1-3
TABLE 14 24kVA 3-Phase PDUs
PDU A PDU B
M2-3 M1-3
M2-2 M1-2
M2-1 M1-1
M1-3 M2-3
Low Voltage
Warning (Amps) Alarm (Amps)
10 13
12 15
20 25
Low Voltage
Warning (Amps) Alarm (Amps)
9 12
6 8
8 11
15 19
17 22
17 22
Low Voltage
Warning (Amps) Alarm (Amps)
18 23
20 25
20 25
Low Voltage
Warning (Amps) Alarm (Amps)
16 20
20 26
15 20
15 19
Reviewing Power Requirements
High Voltage
Warning (Amps) Alarm (Amps)
9 12
10 14
18 23
High Voltage
Warning (Amps) Alarm (Amps)
6 8
4 5
3 4
8 10
8 10
10 14
High Voltage
Warning (Amps) Alarm (Amps)
17 21
18 23
18 23
High Voltage
Warning (Amps) Alarm (Amps)
6 8
11 14
10 14
8 10
