Oracle SuperCluster T5-8 Owner's Manual page 246

Connector Locations
■
ZFS storage controllers
■
■
■
Exadata Storage Servers
■
■
■
■
■
■
■
■
■
The Ethernet Management Switch
■
Catalyst 4948 Ethernet Switch) ," on page
PDU circuit breakers and AC sockets
■
the PDU," on page
FIGURE 24
Figure Legend
1
NET MGT 0 and NET MGT 1 ports
2
InfiniBand ports 0A-17A (upper ports)
3
InfiniBand ports 0B-17B (lower ports)
246 Oracle SuperCluster T5-8 Owner's Guide • May 2016
SPARC T5-8 No. 2 (slot 18)
(Figure 28, "ZFS Storage Controller," on page
ZFS storage controller No. 1 (slot 33)
ZFS storage controller No. 2 (slot 34)
(Figure 29, "Exadata Storage Server ," on page
Exadata Storage Server No. 1 (slot 2)
Exadata Storage Server No. 2 (slot 4)
Exadata Storage Server No. 3 (slot 6)
Exadata Storage Server No. 4 (slot 8)
Exadata Storage Server No. 5 (slot 35) (Full Rack only)
Exadata Storage Server No. 6 (slot 37) (Full Rack only)
Exadata Storage Server No. 7 (slot 39) (Full Rack only)
Exadata Storage Server No. 8 (slot 41) (Full Rack only)
252)
Sun Datacenter InfiniBand Switch 36
(Figure 30, "Ethernet Management Switch (Cisco
251)
(Figure 31, "Circuit Breakers and AC Sockets on
249):
250):
