Leaf Switch
R2-U26 to Rack 1

Three-Rack Cabling

The following table shows the cable connections for the first spine switch (R1-U1) when
cabling three full racks together.
TABLE 24
Leaf Switch
R1-U32 within Rack 1
R1-U32 to Rack 2
R1-U32 to Rack 3
R1-U26 within Rack 1
R1-U26 to Rack 2
R1-U26 to Rack 3
Connection
R2-U26-P8B to R2-U1-P4B
R2-U26-P9A to R2-U1-P5B
R2-U26-P9B to R2-U1-P6B
R2-U26-P10A to R1-U1-P7B
R2-U26-P10B to R1-U1-P8B
R2-U26-P11A to R1-U1-P9B
R2-U26-P11B to R1-U1-P10B
Leaf Switch Connections for the First Rack in a Three-Rack System
Connection
R1-U32-P8A to R1-U1-P3A
R1-U32-P8B to R1-U1-P4A
R1-U32-P9A to R1-U1-P5A
R1-U32-P9B to R2-U1-P6A
R1-U32-P10A to R2-U1-P7A
R1-U32-P10B to R2-U1-P8A
R1-U32-P11A to R3-U1-P9A
R1-U32-P11B to R3-U1-P10A
R1-U26-P8A to R1-U1-P3B
R1-U26-P8B to R1-U1-P4B
R1-U26-P9A to R1-U1-P5B
R1-U26-P9B to R2-U1-P6B
R1-U26-P10A to R2-U1-P7B
R1-U26-P10B to R2-U1-P8B
R1-U26-P11A to R3-U1-P9B
R1-U26-P11B to R3-U1-P10B
Cable Length
5 meters
Cable Length
5 meters
5 meters
5 meters
5 meters
5 meters
5 meters
Connecting Multiple Oracle SuperCluster T5-8 Systems
Three-Rack Cabling
265
