Table 71, "Oracle ILOM Cabling for the Expansion Rack (Full Rack)," on page 305
■
Table 72, "Oracle ILOM Cabling for the Expansion Rack (Half Rack)," on page 305
■
Table 73, "Oracle ILOM Cabling for the Expansion Rack (Quarter Rack)," on page 306
■
TABLE 71 Oracle ILOM Cabling for the Expansion Rack (Full Rack)
From Rack Unit Type of Equipment
U41 Exadata Storage Server
U39 Exadata Storage Server
U37 Exadata Storage Server
U35 Exadata Storage Server
U33 Exadata Storage Server
U31 Exadata Storage Server
U29 Exadata Storage Server
U27 Exadata Storage Server
U25 Exadata Storage Server
U18 Exadata Storage Server
U16 Exadata Storage Server
U14 Exadata Storage Server
U12 Exadata Storage Server
U10 Exadata Storage Server
U8 Exadata Storage Server
U6 Exadata Storage Server
U4 Exadata Storage Server
U2 Exadata Storage Server
Oracle ILOM Cabling for the Expansion Rack (Half Rack)
TABLE 72
From Rack Unit Type of Equipment
U18 Exadata Storage Server
U16 Exadata Storage Server
U14 Exadata Storage Server
U12 Exadata Storage Server
U10 Exadata Storage Server
U8 Exadata Storage Server
U6 Exadata Storage Server
U4 Exadata Storage Server
U2 Exadata Storage Server
Understanding Expansion Rack Internal Cabling
Gigabit Ethernet Port
2
4
6
8
10
12
14
18
22
26
30
32
34
36
38
40
42
44
Gigabit Ethernet Port
26
30
32
34
36
38
40
42
44
