Reviewing Power Requirements

"Power Consumption" on page 99
■
"Facility Power Requirements" on page 100
■
"Grounding Requirements" on page 100
■
"PDU Power Requirements" on page 101
■
"PDU Thresholds" on page 104
■

Power Consumption

These tables describe power consumption of SuperCluster T5-8 and expansion racks.
These are measured values and not the rated power for the rack. For rated power specifications,
see "PDU Power Requirements" on page
TABLE 4
Condition
Maximum
Typical
TABLE 5
Product
Extreme Flash quarter rack
High capacity quarter rack
Individual Extreme Flash storage server
Individual High capacity storage server
SuperCluster T5-8
Exadata X5-2 Expansion Rack
101.
Full Rack
15.97 kVA
15.17 kW
13.31 kVA
12.64 kW
Condition
Maximum
Typical
Maximum
Typical
Maximum
Typical
Maximum
Typical
Reviewing Power Requirements
Half Rack
9.09 kVA
8.6 kW
7.5 kVA
7.13 kW
kW kVA
3.6 3.7
2.5 2.6
3.4 3.4
2.4 2.4
.6 .6
.4 .4
.5 .5
.4 .4
Preparing the Site 99
