Oracle SuperCluster T5-8 Owner's Manual page 275

Leaf Switch
R3 U32 to Rack 1
R3 U32 to Rack 2
R3 U32 to Rack 4
R3 U32 to Rack 5
R3 U32 to Rack 6
R3 U26 within Rack 3
R3 U26 to Rack 1
R3 U26 to Rack 2
R3 U26 to Rack 4
R3 U26 to Rack 5
R3 U26 to Rack 6
The following table shows the cable connections for the fourth spine switch (R4-U1) when
cabling six full racks together.
TABLE 39 Leaf Switch Connections for the Fourth Rack in a Six-Rack System
Leaf Switch
R4 U32 within Rack 4
R4 U32 to Rack 1
R4 U32 to Rack 2
R4 U32 to Rack 3
R4 U32 to Rack 5
R4 U32 to Rack 6
R4 U26 within Rack 4
R4 U26 to Rack 1
R4 U26 to Rack 2
R4 U26 to Rack 3
R4 U26 to Rack 5
Connection
R3-U32-P11A to R1-U1-P9A
R3-U32-P11B to R2-U1-P10A
R3-U32-P9A to R4-U1-P5A
R3-U32-P9B to R4-U1-P6A
R3-U32-P10A to R5-U1-P7A
R3-U32-P10B to R6-U1-P8A
R3-U26-P8A to R3-U1-P3B
R3-U26-P8B to R3-U1-P4B
R3-U26-P11A to R1-U1-P9B
R3-U26-P11B to R2-U1-P10B
R3-U26-P9A to R4-U1-P5B
R3-U26-P9B to R4-U1-P6B
R3-U26-P10A to R5-U1-P7B
R3-U26-P10B to R6-U1-P8B
Connection
R4-U32-P8A to R4-U1-P3A
R4-U32-P8B to R4-U1-P4A
R4-U32-P10B to R1-U1-P8A
R4-U32-P11A to R2-U1-P9A
R4-U32-P11B to R3-U1-P10A
R4-U32-P9A to R5-U1-P5A
R4-U32-P9B to R5-U1-P6A
R4-U32-P10A to R6-U1-P7A
R4-U26-P8A to R4-U1-P3B
R4-U26-P8B to R4-U1-P4B
R4-U26-P10B to R1-U1-P8B
R4-U26-P11A to R2-U1-P9B
R4-U26-P11B to R3-U1-P10B
R4-U26-P9A to R5-U1-P5B
R4-U26-P9B to R5-U1-P6B
Connecting Multiple Oracle SuperCluster T5-8 Systems
Six-Rack Cabling
Cable Length
5 meters
5 meters
5 meters
5 meters
5 meters
3 meters
5 meters
5 meters
5 meters
5 meters
5 meters
Cable Length
3 meters
10 meters
5 meters
5 meters
5 meters
5 meters
3 meters
10 meters
5 meters
5 meters
5 meters
275
