j. Click Finish.
k. Under the Network Channels table, select ReplicationChannel, the network
channel you created for the WLS1 Managed Server.
l. Expand Advanced, and select Enable SDP Protocol.
m. Click Save.
n. To activate these changes, in the Change Center of the Administration
Console, click Activate Changes.
You must repeat the above steps to create a network channel each for the remaining
Managed Servers in the Dept1_Cluster1 cluster. Enter the required properties, as described
in the following table.
Managed Servers in Name
Dept1_Cluster1
WLS2 ReplicationChannel
WLS3 ReplicationChannel
WLS4 ReplicationChannel
WLS5 ReplicationChannel
WLS6 ReplicationChannel
WLS7 ReplicationChannel
WLS8 ReplicationChannel
4. After creating the network channel for each of the Managed Servers in your
cluster, click Environment > Clusters. The Summary of Clusters page is
displayed.
5. Click Dept1_Cluster1 (this is the example cluster to which you will deploy a web
application at a later time). The Settings for Dept1_Cluster1 page is displayed.
6. Click the Replication tab.
7. In the Replication Channel field, ensure that ReplicationChannel is set as the
name of the channel to be used for replication traffic.
8. In the Advanced section, select the Enable One Way RMI for Replication option.
9. Click Save.
Enable Cluster-Level Session Replication Enhancements
Protocol Listen Address
t3 10.0.0.2
t3 10.0.0.3
t3 10.0.0.4
t3 10.0.0.5
t3 10.0.0.6
t3 10.0.0.7
t3 10.0.0.8
Listen Port Additional Channel Ports
7005 7006 to 7014
7005 7006 to 7014
7005 7006 to 7014
7005 7006 to 7014
7005 7006 to 7014
7005 7006 to 7014
7005 7006 to 7014
