IBM eserver i5 Handbook page 455

Draft Document for Review October 18, 2004
Machine Desktop
model 3490E-F10
Rack
3490E-F11
Library
9
3490-F1A
3
Controllers #2749
supported
Minimum OS/400
operating V4R1
system level
Alternate IPL #5504
device specify
Notes:
1. The actual degree of compression achieved is highly sensitive to the characteristics of the data compressed.
2. This entry illustrates the best possible performance. Other components of the system may limit the actual performance achieved.
The best source of information about performance is the iSeries Performance Capabilities Reference, SC41-0607.
3. The #2749 PCI Ultra Magnetic Media Controller attachment requires a minimum of OS/400 V4R5.
4. The #2765 PCI Fibre Channel Tape Controller attachment requires a minimum of OS/400 V5R1.
5. The #2765 PCI Fibre Channel Tape Controller supports attachment to the 3582, 3583, and 3584 only.
6. The #2765 PCI Fibre Channel Tape Controller supports attachment to the 3590-Exx and 3590-Hxx only.
7. The 3590 capacities depend on cartridge type. The Extended High Performance Cartridge has twice the capacity of the original
High Performance Cartridge. The compressed capacities assume 3:1 compression.
8. Minimum operating system to support the #5702 PCI-X Ultra Tape Controller, #5704 PCI-X Fibre Channel Tape Controller and
#5705 PCI-X Tape/DASD Controller attachment is OS/400 V5R2.
9. The maximum number of drives depends on the adapter used to attach to the iSeries server:
– #2765, #5702: 16 drives, media changers, or both per adapter with a maximum of 96 devices in the library partition.
– OS/400 is limited to 32 drives pooled per library, regardless of how the drives are attached (one versus multiple).
10. Minimum operating system to support #5712 PCI-X Tape/DASD Controller attachment: i5/OS V5R3.
11. Minimum operating system to support #2765 attachment: OS/400 V5R1.
Minimum operating system to support #5704 attachment: OS/400 V5R2
12. Multiple frame combinations are possible.
3494-L12 Desktop
3494-L22 3570-C01
3494-L10 3570-C02
3494-D12
3494-D22 Rack
3494-D10 3570-C11
3494-HA1 3570-C12
3
Depends on #2749
installed
drives
See
3590-X1A
and
3592-J1A
column
OS/400 OS/400 V3R1
V2R3
Depends on #5515
tape
devices
installed.
See
3590-X1A
and
3592-J1A
column
External tape, DVD-RAM, optical, disk storage, and SAN components
3575-L06 Desktop/Rack
3575-L12 3581-L28, F28
3575-L18 3582-L23
3575-L24
3575-L32 Library, Floor/Rack
3583-L18
3583-L36
3583-L72
Library
3584-L52, L22, L32
3584-D52, D22, D32
3 3
#2749 #2749
4, 5
#2765
8
#5702
8
#5704
8
#5705
10
#5712
OS/400 V4R1 OS/400 V5R1
#5515 #5537
5486ExtStor.fm
3590-B1A
3590-B11
3590-E1A
3590-E11
3590-H1A
3590-H11
3592-J1A
9
3590
3
#2749
4, 6
#2765
11
#5704
3592
11
#2765, #5704
B1x: OS/400 V3R1
E1x: OS/400 V4R1
H1x: OS/400 V4R5
: OS/400
J1A
V5R1
#5519 for 3590
421
