Model overview

This section takes a closer look at the minimum functional server, required
features, and optional features.

Minimum functional server

A minimum functional server consists of the base server unit and selected priced
features. The base server includes:
Physical package and power elements
Seven PCI card slots
– No hot plugging of PCI cards with #2465, #2466, and #2467 processors
– Hot plugging of PCI cards is supported with the #2769 processor
Operator panel
Base direct access storage device (DASD) cage (six internal disk slots)
Supports concurrent maintenance
Two removable media slots
Embedded Base PCI IOP (CCIN 286D, CCIN 286E)
Provides support for a maximum of up to four input/output adapters (IOAs),
including:
– A PCI disk controller (Small Computer System Interface (SCSI) IOA)
– #9749 Base PCI 100/10 Ethernet IOA
– #9771/#9793/#9794 Base PCI Two-Line WAN with integrated modem
– Base console/workstation IOA
The IBM marketing configurator determines which feature combinations
are to be on the order based on the #5540, #5544, #5546, or #5548
System Console specify code.

Required features

required
The
Specific combinations of the Processor feature, Edition feature, and Server
feature are allowed as shown in the following table.
IBM Eserver i5 and iSeries System Handbook
194
features include:
