Note:
Main storage
See "Main storage" on page 210 for a list of supported memory features, and
configuration considerations.
PCI disk controller (Small Computer System Interface (SCSI) IOA)
The SCSI IOA supports the DVD-ROM, DVD-RAM, migrated CD-ROM,
internal tape, and disk units (in the CEC).
The Model 825 system unit supports three disk unit cages (five-pack) and two
removable media bays.
– #2757 PCI-X Ultra RAID Disk Controller
– #2780 PCI-X Ultra4 RAID Disk Controller
– #2782 PCI-X RAID Disk Unit Controller
– #4778 PCI RAID Disk Unit Controller
– #5703 PCI-X RAID Disk Unit Controller
Note: The PCI SCSI Disk Controller must have its SCSI bus 0 cabled to
the base (upper) DASD cage. The Load Source DASD must be placed in
the base DASD cage.
Removable optical device (one must be specified)
– #4630 DVD-RAM
– #4631 DVD-ROM (Default)
Internal disk units
– #4317 8.58 GB 10k RPM Disk Unit *
– #4318 17.54 GB 10k RPM Disk Unit *
– #4319 35.16 GB 10k RPM Disk Unit
– #4326 35.16 GB 15k RPM Disk Unit
– #4327 70.56 GB 15k RPM Disk Unit
One of the following load source specify codes is required:
– #0829 - #4318 Load Source Specify*
– #0830 - #4319 Load Source Specify
– #0834 - #4326 Load Source Specify
– #0835 - #4327 Load Source Specify
IBM Eserver i5 and iSeries System Handbook
208
– * supported for conversion only
– **supported on upgrade
