0553 2.0M Rack - IBM eserver i5 Handbook

5486Towr.fm
– An #0551 iSeries Rack is required for mounting a Model 825, but the
#0551 is not required on the order or on the inventory records for the
system that is ordering a #0138 Field Install in Rack.
#0123 #5074 Lower Unit in Rack Specify (
December 2002)
#0125 #9079 Lower Unit in Rack Specify (
May 2003)
#0127 270 Field Install in Rack Specify (
May 2003)

#0553 2.0m Rack

The #0553 is a 19 inch wide 2 meter high rack which contains 42 EIA units of
space. The #0553 can be ordered as a feature of an iSeries or i5 server as part
of an initial order or added at a later time.
The following features specify the means of populating the #0553 rack.
#0133 Plant Install in Rack
#0137 Field Install in Rack
#0138 Field Install in Rack
#0578 PCI Expansion Unit in Rack
#0588 PCI-X Expansion Unit in Rack
#0595 PCI-X Tower Unit in Rack
#7884 520 Rack Mount
One of the following features is required on the #0553:
#6069 - Optional Front Door for 2.0m Rack
#6247 - Enhanced No Door Trim Kit
#6249 - 2.0m Rack Acoustic Door
The following are optional features for the #0553 rack:
#6580 - Optional Rack Security Kit
#7780 - 2.0m Rack Side Attach Kit
#7841 - Ruggedize Rack Kit (Brace, Bolt Down Hardware, Metal Filler Panels)
The IBM marketing configurator does not manage rack space in the #0553
iSeries Rack. Use the table on page 276 to determine the number of EIA units
IBM Eserver i5 and iSeries System Handbook
290
Note: For system units being mounted in the upper portions of a rack
and not utilizing the #1422 PDU cord, be sure the line cord (and SPCN
cable, if present) is of sufficient length.
Draft Document for Review October 18, 2004
withdrawn from marketing
withdrawn from marketing
withdrawn from marketing
on 03
on 07
on 07
