Peripheral Component Interconnect (PCI) and Common Service Processor
(CSP) card (CCIN 28AA)
Operator Panel (CCIN 247A)
Four MCM sockets for up to four processor modules
Eight main storage card sockets
Four slots for base and feature high-speed link (HSL)-2 adapters
#9730 Base HSL-2 Ports - 4 Copper (CCIN 273B)
#9771/#9793/#9794 Base PCI Two-Line WAN with integrated modem
#9844 Base PCI IOP provides support for:
– The required SCSI IOA which controls up to 15 disk units, the required
DVD-RAM/DVD-ROM, and a feature internal tape or a feature
DVD-RAM/DVD-ROM
– A base Console/Workstation IOA
The IBM marketing configurator determines which feature combinations
are placed on the order based on the #5540, #5544, #5546, or #5548
System Console specify code.
– The #9771/#9793/#9794 Base PCI Two-Line WAN with integrated modem
Note: In countries (or regions) where #9771/#9793/#9794 is not
homologated, the marketing configurator adds a #4745 PCI 2-line WAN
IOA or a #2742 Two-Line WAN IOA, a #0032 modem feature, and a
#0348 cable to the order. The #4745/#2742 is mandatory and cannot
be removed from the system until the #9793/#9794 homologation is
completed. The #0032 and #0348 features may be removed from the
order or system at any time.
