Allowable main storage increments (MB)
1152
2176
3200
At least one LAN IOA is required. Refer to the "PCI card placement rules for the
iSeries server" chapter of the IBM Eserver iSeries and AS/400e System
Builder, SG24-2155, for complete rules for placing these PCI cards in
configurations.
The #2799 or #2899 supports up to three, in any combination, of these LAN IOA
features:
#2743 1 Gbps PCI Ethernet IOA
#2760 PCI 1 Gbps Ethernet UTP Adapter
#4838 PCI 100/10 Mbps Ethernet IOA
#2744 PCI 100 Mbps Token Ring IOA
One #0225 (1 Gbps Ethernet on the Integrated xSeries Server) is required for
each 1 Gbps Ethernet adapter selected to run on the #2799 or #2899.
One #0224 (100/10 Mbps Ethernet on the Integrated xSeries Server) is required
for each #4838 selected to run on the #2799 or #2899.
One #0223 (100 Mbps Token-Ring on the Integrated xSeries Server) is required
for each #2744 selected to run on the #2799 or #2899.
Native iSeries functions are not supported. The #2799 or #2899 servers do not
support external host LAN.
The #2899 requires two PCI card slots on the Model 270 system unit. One slot is
consumed. The second slot is reduced to a short card slot, which is then used by
the first attached LAN IOA card.
The #2799 requires three PCI card slots on the Model 820, 830 or 840 system
unit backplane. Two slots are consumed by the #2799. The third slot is reduced
to a short card slot, which is then used by the first LAN IOA card.
The #2799 or #2899 requires three PCI card slots on the expansion tower
backplane. Two slots are consumed by the #2799 or #2899. The third slot is
reduced to a short card slot, which is then used by the first LAN IOA card.
The #2799 or #2899 ships with a keyboard or mouse splitter cable. The #2799 or
#2899 supports only the Windows NT and Windows 2000 operating systems.
These points apply:
IBM Eserver i5 and iSeries System Handbook
330
1280 1408 1536
2304 2432 2560
3328
Draft Document for Review October 18, 2004
1664 1792 2048
3072
4096
