- Page 1 IBM Systems Quick start guide for i5 520, 525, and 515 (9405-520, 9406-520, 9406-525, and 9407-515)
-
Page 2: Before You Begin
This Quick start guide contains an abbreviated set of setup instructions designed to help you quickly unpack and set up a standard system. Users unfamiliar with this IBM hardware should use the fully detailed, setup instructions that you can find in the IBM Systems Hardware Information Center. For details about how to... - Page 3 CD (SK3T-8159). Make sure you received all of the parts that you ordered. Your order information should be located in an envelope adhered to the outside of your system box. You can also obtain order information from your marketing representative or IBM Business Partner.
- Page 4 Prepare the rack for installation If you are installing your server into a new rack, ensure that you have completed the unpacking instructions that were provided with the rack. If your server is already installed in a rack, skip to task 7 Cable the server and Operations Console (LAN).
-
Page 5: Install The Slide Rail Assemblies
Install the slide rail assemblies If you do not have enough space around your rack to open the front and back doors completely, remove the doors before starting this task to allow adequate access. Locate the rack-mounting template, the rack-mounting hardware kit, and the slide rail assemblies that were included with your server. - Page 6 3. Align the retracted back pins with the holes identified by the self-adhesive placement dots. Place the rack flange between the slide-rail flange and the retracted alignment pins . Press the back latch-assembly-release tab to extend the back alignment pins into the back of the rack.
- Page 7 Install the server onto the slide rail assembly Before installing the server onto the slide rail assembly, ensure that the leveling feet are extended and that the stabilizer bracket is correctly installed to prevent the rack from falling forward. Before you begin: Read this entire task before completing any individual steps. Attach the four blue knobs to the server .
-
Page 8: Install The Cable-Management Arm
Install the cable-management arm Locate the cable-management arm and the two pins . Tip: If space is limited inside the rack, slide the server out part of the way to install the cable-management arm. From the back of the rack, use the pin to affix the cable-management arm the left slide-rail-management arm flange that is attached to the rack frame . - Page 9 The following steps guide you through a LAN implementation of Operations Console. If you are using a local console that is directly attached, follow the setup instructions in the IBM Systems Hardware Information Center. For details about how to access the information center, see task 11...
- Page 10 . The server is not yet powered on. 01 B N V=F Note: does not display, see the instructions in the IBM Systems Hardware Information Center. For details about how to access the information center, see task 11 Finish your system setup Press the white Power On button on the front of the server.
- Page 11 This task assumes that you are setting up the Thin Console with a new server. If you are setting up the Thin Console with an existing server, follow the instructions in the IBM Systems Hardware Information Center. For details about how to access the information center, see task 11...
- Page 12 If you are using a rack-mounted HMC, these steps assume it is already installed in the rack. If you need to install the HMC into the rack, follow the instructions in the IBM Systems Hardware Information Center, and return to this guide when you are ready to begin cabling your HMC. For details about how to access the information center, see task 11 Finish your system setup.
- Page 13 Start and configure the HMC, which includes the Guided Setup Wizard. You can find the 9.10 instructions for configuring the HMC in the IBM SystemsHardware Information Center. For details about how to access the information center, see task 11 Finish your system setup Connect the server to a power source and wait for the control panel on the front of the 9.11...
- Page 14 Cable the server and twinaxial console If you are not using a twinaxial console to manage your server, go to task 11 Finish your system setup. Route the power cords through the rings or clamps, if available, on the back of the server, 10.1 and connect to the server.
- Page 15 . Follow these steps to create a customized checklist that helps you configure your server and console, install software, apply fixes, and establish connections with your service provider: Using a Web browser, go to www.ibm.com/systems/infocenter/hardware or go to the 11.1 preinstalled version on the HMC.
- Page 16 IBM intends to make them available in every country or region. i5/OS, IBM, the IBM logo, iSeries, and System i are trademarks of International Business Machines Corporation in the United States, other countries, or both.
