See "Main storage" on page 243 for a list of supported memory features and
configuration considerations.
PCI disk controller (SCSI IOA)
The SCSI IOA supports the DVD-ROM, DVD-RAM, migrated CD-ROM,
internal tape, and disk units in the base PCI enclosure.
– #2757 PCI-X Ultra RAID Disk Controller
– 2780 PCI-X Ultra4 RAID Disk Controller
– #4748 PCI RAID Disk Unit Controller *
– #4778 PCI RAID Disk Unit Controller *
Removable optical device (one must be specified)
– #4425 CD-ROM *
– #4430 DVD-RAM *
– #4625 CD-ROM ***
– #4630 DVD-RAM
– #4631 DVD-ROM
Internal disk units
– #4317 8.58 GB 10k RPM Disk Unit *
– #4318 17.54 GB 10k RPM Disk Unit *
– #4319 35.16 GB 10k RPM Disk Unit
– #4326 35.16 GB 15k RPM Disk Unit
– #4327 70.56 GB 15k RPM Disk Unit
One of the following load source specify codes is required:
– #0829 - #4318 Load Source Specify *
– #0830 - #4319 Load Source Specify
– #0834 - #4326 Load Source Specify
– #0835 - #4327 Load Source Specify
Disk protection specify codes (one must be specified)
– #0040 Mirrored System Disk Level
– #0041 RAID Protection - All
– #0042 Mirrored System IOP Level
– #0043 Mirrored System Bus Level
#0041 is the default for disk data protection.
System console/communications adapter
The console on LAN options requires a dedicated LAN adapter. A #0367
Operations Console PCI Cable is added to the order by the marketing
configurator.
– #5540 System Console on Twinaxial Workstation IOA
• #4746 PCI Twinaxial IOA
