– #4327 70.56 GB 15k RPM Disk Unit
One of the following load source specify codes is required:
– #0829 - #4318 Load Source Specify *
– #0830 - #4319 Load Source Specify
– #0834 - #4326 Load Source Specify
– #0835 - #4327 Load Source Specify
Disk protection specify codes (one must be specified)
– #0040 Mirrored System Disk Level
– #0041 RAID Protection - All
– #0042 Mirrored System IOP Level
– #0043 Mirrored System Bus Level
#0041 is the default for disk data protection.
System console/communications adapter
The console on LAN options require a dedicated LAN adapter. A #0367
Operations Console PCI Cable is added to the order by the marketing
configurator.
– #5540 System Console on Twinaxial Workstation IOA
• #4746 PCI Twinaxial IOA
– #5544 System Console on Operations Console
• #0367 Operations Console PCI Cable
– #5546 System Console on 100 Mbps Token Ring
• #2744 PCI 100 Mbps Token Ring IOA
• #0367 Operations Console PCI Cable
– #5548 System Console on 100 Mbps Ethernet
• #2849 10/100 Mbps Ethernet Adapter – or –
• #4838 PCI 100/10 Mbps Ethernet IOA
• #0367 Operations Console PCI Cable

Optional features

optional
The
#4482 4 GB ¼-inch Cartridge Tape Device *
#4483 16 GB ¼-inch Cartridge Tape Device
#4486 25 GB ¼-inch Cartridge Tape Device
#4487 50 GB ¼-inch Cartridge Tape Device *
#4682 4 GB ¼-inch Cartridge Tape Device
#4684 30 GB ¼-inch Cartridge Tape Device
#4685 80 GB VXA-2 Tape Device
features include the following internal tape devices:
