Draft Document for Review October 18, 2004
Disk protection specify codes (one must be specified)
– #0040 Mirrored System Disk Level
– #0041 RAID Protection - All
– #0042 Mirrored System IOP Level
– #0043 Mirrored System Bus Level
#0041 is the default for disk data protection.
System console attachment adapter
The console on LAN options require a dedicated LAN adapter. A #0367
Operations Console PCI Cable is added to the order by the IBM marketing
configurator.
– #5540 System Console on Twinaxial Workstation IOA
• #4746 PCI Twinaxial IOA
– #5544 System Console on Operations Console
• #0367 Operations Console PCI Cable
– #5548 System Console on 100 Mbps Ethernet
• Embedded 10/100 Mbps Ethernet IOA (CCIN 288E)
• #0367 Operations Console PCI Cable
Note: The #5546 System Console on 100 Mbps Token Ring is not
supported.

Optional features

optional
The
#0551 iSeries Rack
Up to two Model 825s may be installed in an #0551 rack. See "#0551 iSeries
Rack" on page 285 for a complete description of the #0551 iSeries Rack and
supported features and specify codes.
#7124 DASD Expansion Unit - 5 slot
The #7124 is a 5-pack DASD cage for the Model 825 system unit. The #7124
includes the DASD cage, DASD backplane, and associated SCSI cables. A
maximum of two may be ordered on a Model 825 system.
Internal tape devices
– #4682 4 GB ¼-inch Cartridge Tape Device
– #4684 30 GB ¼-inch Cartridge Tape Device
– #4685 80 GB VXA-2 Tape Device
– #4687 50 GB ¼-inch Cartridge Tape Device
features include:
5486M825.fm
209
iSeries Model 825
