Instrument Specification - Swann AMI Codes-II CC Operator's Manual

AMI Codes-II CC
Product Description
2.1.
Power Supply
Electronics
housing
Sample
requirements
On-site
requirements
Measuring
Range
16

Instrument Specification

Voltage:
Power consumption:
Aluminium with a protection degree of IP 66/NEMA 4X
Ambient temperature:
Limit range of operation:
Storage and transport:
Humidity:
Display:
Flow rate:
Temperature:
Inlet pressure:
Outlet pressure:
NOTICE: No oil, no grease, no sand.
The analyzer site must permit connections to:
Sample inlet:
Sample outlet:
Max. Altitude:
Free chlorine, monochloramine, total residual chlorine
0.00–1.00 ppm
1.00–3.00 ppm
3.00–5.00 ppm
pH measurement (optional)
2–12 pH
100–240 VAC (± 10%)
50/60 Hz (± 5%)
or 24 VDC (± 10%)
max. 30 VA
-10 to +50 °C
-25 to +65 °C
-30 to +85 °C
10–90% rel., non condensing
backlit LCD, 75 x 45 mm
min. 10 l/h
5–50 °C (41–122 °F)
0.15–2 bar (2–28 PSI)
pressure free
Tube 6 x 8 mm
1/2" hose nozzle for flexible tube
diam. 20x15 mm
2000 m above sea level
± 0.01 ppm
± 0.06 ppm
± 0.2 ppm
0.01 pH
A-96.250.581 / 220616
