AMI Codes-II CC
Program List and Explanations
5.3.1.1.2
5.3.1.1.2.1
5.3.1.1.2.26
5.3.1.1.2.36
5.3.1.1.2.46
5.3.1.1.3
5.3.1.1.3.1
5.3.1.1.3.26
5.3.1.1.3.36
5.3.1.1.3.46
94
Total chlorine 1
Alarm High: If the measured value rises above the alarm high val-
ue, the alarm relay is activated and E003 is displayed in the mes-
sage list. Range: 0.00–10.00 ppm
Alarm Low: If the measured value falls below the alarm low value,
the alarm relay is activated and E004 is displayed in the message
list.
Range: 0.00–10.00 ppm
Hysteresis: Within the hyst. range, the relay does not switch. This
prevents damage of relays contacts when the measured value fluc-
tuates around the alarm value.
Range. 0.00–10.00 ppm
Delay: Duration, the activation of the alarm relay is retarded after
the measuring value has risen above/fallen below the programmed
alarm.
Range: 0.00–28'800 Sec
Total chlorine 2
Alarm High: If the measured value rises above the alarm high val-
ue, the alarm relay is activated and E005 is displayed in the mes-
sage list. Range: 0.00–10.00 ppm
Alarm Low: If the measured value falls below the alarm low value,
the alarm relay is activated and E006 is displayed in the message
list.
Range: 0.00–10.00 ppm
Hysteresis: Within the hyst. range, the relay does not switch. This
prevents damage of relays contacts when the measured value fluc-
tuates around the alarm value.
Range. 0.00–10.00 ppm
Delay: Duration, the activation of the alarm relay is retarded after
the measuring value has risen above or fallen below the pro-
grammed alarm.
Range: 0.00–28'800 Sec
