AMI Codes-II CC

Default Values

11.
Operation:
Sensors:
Alarm Relay
Relay 1 and 2
Input
Logger:
Display
Installation:
Sensor:
Signal Output
1 and 2
106
Default Values
NOTICE: The parameter Cleaning is only visible if an optional
Cleaning Module is connected to the AMI Codes II.
The parameters pH and Temperature are only visible if the
option pH is installed.
Filter Time Const.:..................................................................30 Sec
Hold after Cal.:.....................................................................120 Sec
Interval fac: .............................................................................. 5 Min
Interval tc2 ............................................................................. 20 Min
default pH: (If pH option is not installed) ................................... 7 pH
...................................................................... same as in Installation
...................................................................... same as in Installation
...................................................................... same as in Installation
Logger Interval:........................................................... Event Driven
Clear Logger: ................................................................................no
Display 1; Line 1 .................................................... Free av. chlorine
Display 1; Line 2 .......................................................Total chlorine 2
Display 1; Line 3 ....................................................... Calc. comb. cl.
Display 2; Line 1 .......................................................Total chlorine 1
Display 2; Line 2 ................................................. Calc. dichloramine
Display 2; Line 3 .......................................................Total chlorine 2
Dimension:.................................................................................ppm
Interpolation: .................................................................................no
Ref. Verification:.......................................................................0.255
Standard: Standard 1:.......................................................... 7.00 pH
Standard: Standard 2:.......................................................... 9.00 pH
Cleaning.......................................................................... 2 Solutions
Parameter: ............................................................ Free av. chlorine.
Current loop: ..................................................................... 4 - 20 mA
Function: .................................................................................. linear
Scaling: Range low: ...........................................................0.00 ppm
Scaling: Range high:..........................................................5.00 ppm
Scaling: Temperature: Range low: ......................................... 0.0 °C
Scaling: Temperature: Range high:.......................................50.0 °C
Scaling: pH: Range low: ..................................................... 0.00 pH
Scaling: pH: Range high: ................................................... 14.00 pH
A-96.250.581 / 220616
