AMI Codes-II CC
Program List and Explanations
5.3.1.6
5.3.1.6.1
5.3.1.6.26
5.3.1.6.36
5.3.1.6.46
96
Alarm pH: Only available if pH option is installed. Define the mea-
suring value, which should issue an alarm high respectively low.
Alarm High: If the measured value rises above the alarm high val-
ue, the alarm relay is activated and E039 is displayed in the mes-
sage list.
Range: 0–14 pH
Alarm Low: If the measured value falls below the alarm low value,
the alarm relay is activated and E040 is displayed in the message
list
Range: 0–14 pH
Hysteresis: Within the hyst. range, the relay does not switch. This
prevents damage of relays contacts when the measured value fluc-
tuates around the alarm value
Range: 0–14 pH
Delay: Duration, the activation of the alarm relay is retarded after
the measuring value has risen above/fallen below the programmed
alarm.
Range: 0–28'800 Sec
A-96.250.581 / 220616
