AMI Codes-II CC
Program List and Explanations
5.3.2 and 5.3.3
5.3.2.1
5.3.2.20
5.3.2.300
A-96.250.581 / 220616
Relay 1 and 2: The contacts can be set as normally open or nor-
mally closed with a jumper. See
The function of relay contacts 1 or 2 are defined by the user.
NOTICE: The navigation in the menu <Relay 1> and <Relay 2>
is equal. For reason of simplicity only the menu numbers of
Relay 1 are used in the following.
1 First select the functions as:
- Limit upper/lower,
- Control upwards/downwards,
- Timer
- Fieldbus
- End of Batch (relay 2 only)
2 Then enter the necessary data depending on the selected func-
tion.
Function = Limit upper/lower:
When the relays are used as upper or lower limit switches, program
the following:
Parameter: select a process value
Setpoint: If the measured value rises above respectively falls below
the set-point, the relay is activated.
Parameter
Free av. chlorine
Total chlorine 1
Total chlorine 2
Calc. monochl.
Calc. comb. cl.
Calc. dichloramine
Temperature
Sample flow
pH
Relay 1 and 2, p.
Range
0–10 ppm
0–10 ppm
0–10 ppm
0–10 ppm
0–10 ppm
0–10 ppm
-30 to +120 °C
0 –600 B/s
0–14 pH
32.
