Swann AMI Codes-II CC Operator's Manual page 106

AMI Codes-II CC
Program List and Explanations
5.5 Interface
5.5.1
5.5.20
5.5.30
5.5.40
5.5.1
5.5.21
5.5.31
5.5.41
5.5.1
104
Select one of the following communication protocols. Depending on
your selection, different parameters must be defined.
Protocol: Profibus
Device address:
ID-Nr.:
Local operation:
Protocol: Modbus RTU
Device address:
Baud Rate:
Parity:
Protocol: USB-Stick:
Only visible if an USB interface is installed. No further settings are
possible.
Range: 0–126
Range: Analyzer; Manufacturer; Multivariable
Range: Enabled, Disabled
Range: 0–126
Range: 1200–115 200 Baud
Range: none, even, odd
A-96.250.581 / 220616
