AMI Codes-II CC
Program List and Explanations
3.5.1.3
3.5.1.4
3.5.1.5
3.5.2
3.5.3
84
Delay: During cleaning plus the delay time, the status of the signal-
and control outputs is as get below.
Range: 60–6'000 sec
Signal Outputs: Select the operation mode of the signal outputs
during cleaning:
Cont.: Signal outputs continue to issue the measured value.
Hold: Signal outputs hold the last valid measured value.
Measurement is interrupted. Errors, except fatal errors,
are not issued.
Off: Signal outputs are switched off (set to 0 or 4 mA).
Errors, except fatal errors, are not issued.
Output/Control: Relay or signal output:
Cont.: Controller continues normally.
Hold: Controller continues based on the last valid value.
Off: Controller is switched off.
Fill Channel 11: Activates the cleaning pump and switches the
valve to the cleaning solution 1 (right container)
Fill Channel 12: Activates the cleaning pump and switches the
valve to the cleaning solution 2 (left container)
