AMI Codes-II CC
Program List and Explanations
5.3.2.32.1
5.3.2.32.20
5.3.2.32.30
5.3.2.32.4
5.3.2.32.1
5.3.2.32.21
5.3.2.32.31
5.3.2.32.1
5.3.2.32.22
5.3.2.32.32
A-96.250.581 / 220616
Actuator = Time proportional
Examples of metering devices that are driven time proportional are
solenoid valves, peristaltic pumps.
Dosing is controlled by the operating time.
Cycle time: duration of one control cycle (on/off change).
Range: 0–600 Sec.
Response time: Minimal time the metering device needs to react.
Range: 0–240 Sec.
Control Parameters
Range for each Parameter same as
Actuator = Frequency
Examples of metering devices that are pulse frequency driven are
the classic membrane pumps with a potential free triggering input.
Dosing is controlled by the repetition speed of dosing shots.
Pulse frequency: Max. pulses per minute the device is able to re-
spond to. Range: 20–300/min.
Control Parameters
Range for each Parameter same as
Actuator = Motor valve
Dosing is controlled by the position of a motor driven mixing valve.
Run time: Time needed to open a completely closed valve
Range: 5–300 Sec.
Neutral zone: Minimal response time in % of the runtime. If the re-
quested dosing output is smaller than the response time, no
change will take place.
Range: 1–20 %
5.2.1.43, p. 91
5.2.1.43, p. 91
99
