6.2 Tool part list
Item no.
Item designation
109010
Service kit UR3/UR5/UR10
109101
Spanner Hex 5.5mm
109102
Spanner Hex 7.0mm
109110
Spanner Hex 10.0mm
Screwdriver Flat 2.5
109103
Screwdriver torx T10
109105
Torque wrench Hex 5.5mm Size 1 and Size 2 (1.3 Nm)
109106
Torque wrench Hex 7.0mm Size 3 (3.0 Nm)
109107
Torque wrench Hex 10.0mm Size 4 (8.0 Nm)
109104
Torque screwdriver torx T8 + T10 (0.4 Nm)
109111
Torque screwdriver torx T10 (1.3 Nm)
109112
Torque screwdriver torx T20 (3.0 Nm)
164084
Bypass cable (for setting joint-ID)
109180
ESD wrist strap
Service kit box
All rights reserved
(kit includes all of the below part no.'s)
99
Servicemanual_UR5_en_rev2.0.5
UR5 & UR10
UR5 & UR10
UR10 only
UR3 & UR5 & UR10
UR5 & UR10
UR5 & UR10
UR5 & UR10
UR10 only
UR3 & UR5 & UR10
UR3
UR3
UR3 & UR5 & UR10
UR3 & UR5 & UR10
UR3 & UR5 & UR10
