Terminating Resistor Adapter - Lucent Technologies definity Installation Manual

DEFINITY Enterprise Communications Server Release 6
Installation and Test for Compact Modular Cabinets 555-230-128
1 Install and Cable the Cabinets
Install the BRI Terminating Resistor

Terminating Resistor Adapter

Figure 1-33
an 8-wide plug at 1 end, a short cord, and an 8-wide jack at the opposite end.
1
Figure Notes
1. 8-wide plug
Figure 1-33. 8-Wide Terminating Resistor Adapter (440A4)
shows an 8-pin 440A4 terminating resistor adapter. The adapter has
1
2
3
4
5
6
7
8
R C R C
r910013 RPY 012098
2. 8-wide jack
Issue 3
May 1998
Page 1-78
1
2
3
4
2
5
6
7
8
