DEFINITY Enterprise Communications Server Release 6
Installation and Test for Compact Modular Cabinets 555-230-128
1 Install and Cable the Cabinets
Install and Wire Telephones and Other Equipment
Analog Tie Trunk Example
Figure Notes
1. External trunk or adapter
Figure 1-28. Analog Tie Trunk Wiring
1. Before installing the Tie Trunk circuit pack, set the option switches as
described in
2. Install cross-connect jumpers to connect the pins from the Tie Trunk circuit
pack to the appropriate leads on the external tie trunk. Names of the tie
trunk leads must be determined from the manufacturer or supplier of the
external trunk circuit. The example in
System tie trunk connected to a DEFINITY System tie trunk.
3. Administer on the Trunk Group Screen. See DEFINITY Enterprise
Communications Server Release 6 Administration and Feature
Description .
T1 26
1
R1
T11 27
R11 2
E1 28
M1 3
2. Tie trunk circuit pack
Chapter 2, ''Installation Completion and Cable
29 T2
4 R2
30 T12
R12
5
31 E2
6
M2
tie_wire RBP 040596
Figure 1-28 shows a DEFINITY
Issue 3
May 1998
Page 1-59
Pinouts''.
