DEFINITY Enterprise Communications Server Release 6
Installation and Test for Compact Modular Cabinets 555-230-128
1 Install and Cable the Cabinets
CAMA/E911 Installation
22. In the Rte Pat field, type the desired Route Pattern (in the example
above the route pattern is 12).
23. In the Call Type field, enter emer and press
24. At the prompt, type change route-pattern <number> (the route pattern to
be changed; in the example below, the route pattern is 11) and press
Grp. FRL NPA Pfx Hop Toll No. Del Inserted
No.
1: 1__ 0 ___
2: ___ _ ___
3: ___ _ ___
4: ___ _ ___
5: ___ _ ___
6: ___ _ ___
BCC VALUE
0 1 2 3 4 W
1: y y y y y n
2: y y y y y n
3: y y y y y n
4: y y y y y n
5: y y y y y n
6: y y y y y n
Screen 1-9. Route Pattern form (Page 1)
25. On the Route Pattern screen, in Grp. No. field, enter the CAMA trunk
group number.
26. In the FRL field, enter 0.
27. Administer the Inserted Digits field if needed and press
NOTE:
For the following step, if you are using the Attendant Crisis Alerting
feature, type alrt instead of "emer."
Pattern Number: 11
Mrk Lmt List Digits
_ __ __ __
_ __ __ __
_ __ __ __
_ __ __ __
_ __ __ __
_ __ __ __
TSC CA-TSC ITC BCIE Service/Feature
Request
y none_____ both ept
n rest
n rest
n rest
n rest
n rest
NOTE:
For the following step, if the Central Office (CO) wants KP11ST as
the dialed digit string, then leave blank. If the CO wants KP911ST,
then insert a "9" in the Inserted Digits field.
Enter
Digits
____________________________________ user
____________________________________ user
____________________________________ user
____________________________________ user
____________________________________ user
____________________________________ user
outwats-bnd____ BAND: ___ ________
_______________
_______________
_______________
_______________
_______________
Issue 3
May 1998
Page 1-73
.
Enter
Page 1 of X
IXC
Numbering LAR
Format
none
________ next
________ rehu
________ none
________ none
________ none
.
Enter
.
