1 Install and Cable the Cabinets
Install and Wire Telephones and Other Equipment
Local and Phantom Power
An attendant console's maximum distance from the system is limited.
See Table
Table 1-9. Attendant Console Cabling Distances
Enhanced Attendant
Console (302C1)
With Selector Console
Phantom powered
Locally powered
Without Selector Console
Phantom powered
Locally powered
Auxiliary Power
The nonessential functions of an attendant console and its optional 26A1 or 24A1
selector console derive power from an auxiliary power source. Provide auxiliary
power for an attendant console through this cable so the console remains fully
operational during short power outages.
NOTE:
Only 1 console can derive auxiliary power from the system and through the
auxiliary cable located in the trunk/auxiliary field.
A console's maximum distance from its auxiliary power source is:
800 feet (244 m) for a 302A1
350 feet (107 m) for a 301B1 and 302C1
An attendant console can also derive auxiliary power from:
Individual 1151A or 1151A2 power supply
MSP-1 power supply
258A-type adapters
Bulk power supplies such as the 1145A1
1-9.
24 AWG Wire (0.26 mm2)
Feet
800
5000
1400
5000
26 AWG Wire (0.14 mm
Meters Feet
244 500
1524 3400
427 900
1524 3400
Issue 3
May 1998
Page 1-65
2
)
Meters
152
1037
274
1037
