DEFINITY Enterprise Communications Server Release 6
Installation and Test for Compact Modular Cabinets 555-230-128
2 Installation Completion and Cable Pinouts
Connector and Cable Diagrams — Pinout Charts
Connector and Cable Diagrams —
Pinout Charts
See Table 2-6
equipment are classified as shown in the following tables.
Table 2-6. Lead and Color Designations
Cross-Connect
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
for typical lead designations. The circuit packs and auxiliary
Amphenol
Color Pin
W-BL 26
BL-W 01
W-O 27
O-W 02
W-G 28
G-W 03
W-BR 29
BR-W 04
W-SL 30
SL-W 05
R-BL 31
BL-R 06
R-O 32
O-R 07
R-G 33
G-R 08
R-BR 34
BR-R 09
R-SL 35
SL-R 10
BK-BL 36
BL-BK 11
BK-O 37
O-BK 12
Continued on next page
Backplane Pin
102
002
103
003
104
004
105
005
106
006
107
007
108
008
109
009
110
010
111
011
112
012
113
013
Issue 3
May 1998
Page 2-9
