DEFINITY Enterprise Communications Server Release 6
Installation and Test for Compact Modular Cabinets 555-230-128
1 Install and Cable the Cabinets
CAMA/E911 Installation
11. The Feature Access Code (FAC) screen (page 1) appears.
12. In the Auto Route Selection (ARS) Access Code 1: field,
administer the ARS access code (in the example above, type 9) and press
Enter
13. At the prompt, enter change ars analysis <9> and press
Dialed Total
String Mn Mx
9________________ 7_ 7_
976______________ 7_ 7_
11_______________ 2_ 2_
911______________ 3_ 3_
_________________ __ __
_________________ __ __
_________________ __ __
_________________ __ __
_________________ __ __
_________________ __ __
_________________ __ __
_________________ __ __
_________________ __ __
_________________ __ __
_________________ __ __
Screen 1-8. ARS Digit Analysis Table
14. On ARS Digit Analysis Table screen appears. In the Dialed String
field, in the first empty row, enter 11.
15. In the Total Mn field, enter 2.
16. In the Total Mx field, enter 2.
17. In the Rte Pat field, enter the desired Route Pattern (in the example
above the route pattern is 11).
18. In Call Type field, enter emer.
19. On the next empty row, in the Dialed String field, type 911.
20. In the Total Mn field, enter 3.
21. In the Total Mx field, enter 3.
(must match dial plan).
ARS DIGIT ANALYSIS TABLE
Partitioned Group Number:
Rte Call Nd ANI
Pat Type Num
2__ hnpa ___ n __________________ __ __ ___ ____ ___ _
den hnpa ___ n __________________ __ __ ___ ____ ___ _
11_ emer ___ n __________________ __ __ ___ ____ ___ _
12_ emer ___ n __________________ __ __ ___ ____ ___ _
___ ____ ___ _ __________________ __ __ ___ ____ ___ _
___ ____ ___ _ __________________ __ __ ___ ____ ___ _
___ ____ ___ _ __________________ __ __ ___ ____ ___ _
___ ____ ___ _ __________________ __ __ ___ ____ ___ _
___ ____ ___ _ __________________ __ __ ___ ____ ___ _
___ ____ ___ _ __________________ __ __ ___ ____ ___ _
___ ____ ___ _ __________________ __ __ ___ ____ ___ _
___ ____ ___ _ __________________ __ __ ___ ____ ___ _
___ ____ ___ _ __________________ __ __ ___ ____ ___ _
___ ____ ___ _ __________________ __ __ ___ ____ ___ _
___ ____ ___ _ __________________ __ __ ___ ____ ___ _
NOTE:
For the following step, if you are using the Attendant Crisis Alerting
feature, type alrt instead of "emer."
_
Dialed
Rq String
Issue 3
May 1998
Page 1-72
.
Enter
Percent Full:
Total Rte Call Nd ANI
Mn Mx Pat Type Num Rq
___
