DEFINITY Enterprise Communications Server Release 6
Installation and Test for Compact Modular Cabinets 555-230-128
1 Install and Cable the Cabinets
Install Emergency Transfer Unit and Associated Telephones
Table 1-17. Pin Assignments for 25-Pair Connector on 808A
Pin
26
1
27
2
28
3
29
4
30
5
31
6
32
7
33
8
34
9
35
10
36
11
37
12
38
13
39
14
40
Color Designation
W-BL TTC1
BL-W RTC1
W-O TTK1
O-W RTK1
W-G TLC1
G-W RLC1
W-BR TST1
BR-W RST1
W-S TTC2
S-W RTC2
R-BL TTK2
BL-R RTK2
R-O TLC2
O-R RLC2
R-G TST2
G-R RST2
R-BR TTC3
BR-R RTC3
R-S TTK3
S-R RTK3
BK-BL TLC3
BL-BK RLC3
BK-O TST3
O-BK RST3
BK-G TTC4
G-BK RTC4
BK-BR TTK4
BR-BK RTK4
BK-S TLC4
Connector/Description
Tip-PBX Trunk Circuit 1
Ring-PBX Trunk Circuit 1
Tip-CO Trunk Circuit 1
Ring-CO Trunk Circuit 1
Tip-PBX Line Port 1
Ring-PBX Line Port 1
Tip-Emergency Terminal 1
Ring-Emergency Terminal 1
Tip-PBX Trunk Circuit 2
Ring-PBX Trunk Circuit 2
Tip-CO Trunk Circuit 2
Ring-CO Trunk Circuit 2
Tip-PBX Line Port 2
Ring-PBX Line Port 2
Tip-Emergency Terminal 2
Ring-Emergency Terminal 2
Tip-PBX Trunk Circuit 3
Ring-PBX Trunk Circuit 3
Tip-CO Trunk Circuit 3
Ring-CO Line Port 3
Tip-PBX Line Port 3
Ring-PBX Line Port 3
Tip-Emergency Terminal 3
Ring-Emergency Terminal 3
Tip-PBX Trunk Circuit 4
Ring-PBX Trunk Circuit 4
Tip-CO Trunk Circuit 4
Ring-CO Trunk Circuit 4
Tip-PBX Line Port 4
Continued on next page
