DEFINITY Enterprise Communications Server Release 6
Installation and Test for Compact Modular Cabinets 555-230-128
1 Install and Cable the Cabinets
Install and Wire Telephones and Other Equipment
DS1 Tie Trunk Example
DS1 tie trunks provide a 1.544 Mbps (T1) or 2.048 Mbps (E1) digital data service
between 2 collocated systems or between the system and a data network. The
following cables can be used:
C6C connector cable
male connector on 1 end and a 15-pin male connector on the other end.
Use to connect a DS1 tie trunk circuit pack to a Channel Service Unit.
C6D connector cable
male connector on each end. Use to connect a DS1 tie trunks in
collocated cabinets.
C6E connector cable
male connector on 1 end and a 50-pin female connector on the other end.
Use as an "extension" cable between the DS1 tie trunk circuit pack and
other connector cables.
C6F connector cable
male connector on 1 end and a 3 inch (7.62 cm) stub on the other end.
Use to connect the DS1 tie trunk circuit pack to channel multiplexers
requiring hardwired connections. See
Table 1-8. Pinout of C6F Cable
Wire Color
White/Green
Green
White/Brown
Brown
White/Slate
Slate
Collocated DS1 Tie Trunks
Two DS1 tie trunk circuit packs can be in collocated systems. A DS1 tie trunk
circuit pack in 1 system can connect to a DS1 tie trunk in another system. Use a
C6D cable if the distance is less than 50 feet (15.24 m). If the distance is greater
than 50 feet (15.24 m), use a C6E cable.
NOTE:
The maximum distance between cabinets is 1310 feet (399.3 m).
—
50-foot (15.2 m) shielded cable with a 50-pin
—
50-foot (15.2 m) shielded cable with a 50-pin
—
100-foot (30.5 m) shielded cable with a 50-pin
—
50-foot (15.2 m) shielded cable with a 50-pin
Lead Designation
LI (High Side)
LI
LO
LO (High Side)
LBACK2
LBACK1
Table 1-8 for a pinout.
Pin
Number
47
22
48
23
49
24
Issue 3
May 1998
Page 1-61
