DEFINITY Enterprise Communications Server Release 6
Installation and Test for Compact Modular Cabinets 555-230-128
1 Install and Cable the Cabinets
Connect Modem to Telephone Network
8. For non-United States installations, set the remaining modem fields as
shown in
9. Press
Table 1-20. Release 6 CMC Modem Fields
Field Description
Default is none for Release 6 CMC. Set to external if a modem is used.
Modem
Connection
This field is 20 characters long and permits alphanumeric characters to
Modem Name
provide a unique qualifier for a given modem.
Informs modem that communication with the data source UART is driven
RTS/CTS
with RTS/CTS flow control. The default 6-character field name is &H1.
Enabled
Set the field name to \Q3 for Intel modems. This field is not
case-sensitive.
Configures modem as an asynchronous device. This 8-character field
Asynchronous
name has a default value of &M0 (default) for Release 6csi. Set the field
Data Mode
to &M0&Q0 for Intel modems. This field is not case-sensitive.
Adjusts the speed of the data source (DTE) UART to the outgoing
DTE
(modem-to-modem) data rate. At maximum, this speed is 9600 baud. It
Auto-Data
is not desirable to have the serial data fill the modem buffer faster than
Speed
the outgoing data rate, since data compression is disabled. The field
name has a 6-character blank default value. The Paradyne products use
S90=1 to enable this functionality while the Intel product uses \J1 to
enable similar functionality. This field is not case-sensitive.
Turns off the default data compression algorithms used by most
Disable Data
modems. The field has a blank field of 6 characters as default. The AT
Compression
commands that control this are supported by similar commands;
however, these commands do not operate in the same manner. The Intel
modems require H0%C0 to disable V.42bis & MNP Class 5 data
compression algorithms. The Paradyne products only use %C0 to
disable both algorithms. This field is not case-sensitive.
Turns on the V.42 LAPM and MNP error control protocols. The field has a
Enable Error
blank default of 6 characters. The Paradyne products use the command
Control
\N5 to enable V.42/MNP/Buffer error control while the Intel product uses
\N3 to provide similar functionality.
This field has a 20-character blank default and supports any initialization
Misc. Init.
parameters not already specified. The AT commands specified in this
Param
field are always the last initialization parameters to be sent to the
external modem. This field is not case-sensitive.
Table 1-20.
when the modem fields are properly administered.
Enter
Issue 3
May 1998
Page 1-99
