DEFINITY Enterprise Communications Server Release 6
Installation and Test for Compact Modular Cabinets 555-230-128
2 Installation Completion and Cable Pinouts
Connector and Cable Diagrams — Pinout Charts
Table 2-6. Lead and Color Designations — Continued
Cross-Connect
Pin
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
Amphenol
Color Pin
BK-G 38
G-BK 13
BK-BR 39
BR-BK 14
BK-SL 40
SL-BK 15
Y-BL 41
BL-Y 16
Y-O 42
O-Y 17
Y-G 43
G-Y 18
Y-BR 44
BR-Y 19
Y-SL 45
SL-Y 20
V-BL 46
BL-V 21
V-O 47
O-V 22
V-G 48
G-V 23
V-BR 49
BR-V 24
V-SL 50
SL-V 25
Continued on next page
Backplane Pin
302
202
303
203
304
204
305
205
306
206
307
207
308
208
309
209
310
210
311
211
312
212
313
213
300
200
Issue 3
May 1998
Page 2-10
