Aircraft Technical Manual
JTM001-5
Engine Oil Details.
P/No. 5A008A0D
1 OFF
Trim Position
P/No. 5A031A0D
(1 OFF)
Trim Position
P/No5024094
Brake On
P/No. 5A031B0D
Carby Heat
P/No 5A030A0D
Earth on Post
P/No. 5A066A0D
No Step
P/No. 5A006A0D
Qty 2 required.
Earth on Exhaust
P/No. 5029094
Dipstick Inside
P/No. 5A007A0D
Owner's Manual
P/No 5036194
Door Open LHS
P/No5027094
Door Open RHS
P/No 5028094

This document is controlled while it remains on the Jabiru server. Once this no longer applies the document becomes uncontrolled.

ISSUE 1 2 3
Jabiru Aircraft
J120, J160, J170, J200/J400, J230/J430, J250/J450 Variants
Attach to upper cowl beside oil door or to oil door itself.
Fit to centre console beside of elevator fwd stop, between trim levers.
NOSE DOWN
Fitted on the Top of the Main Beam Beside the trim control
Fit to centre console beside brake lever, arrow pointing aft.
Fitted to lower central section of instrument panel.
Attach to upper wing skin beside fuel filler earth post.
Attach to the lower fuselage on the pilot's side immediately above the
Fit to outside of oil door in upper engine cowl.
Fitted to Inside of RH Door above the Door Pocket.
Fitted to the Outsides of LH Door Above the Door Catch Lever
4 5 Dated: 29th October 2014
Pty Ltd
NEUTRAL TRIM NOSE UP
Fit to top of main wheel spats
exhaust outlet pipe.
FLIGHT/OWNERS MANUAL
OPEN
OPEN
Issued By: AS
BRAKE ON
Page: 279 of 298
