Figure 5 – J200 / J400 General Arrangement - Jabiru j160 Technical Manual

Aircraft Technical Manual
JTM001-5
Table 2-5 – J200/J400 Specifications
Model
Number of Seats
Aircraft Maximum Weight
Fuel Capacity
Oil Capacity
Engine Model
Propeller Pitch
Wheel Sizes Standard
Tyres Standard
Tyre Pressures Standard - Mains
Tyre Pressures Standard - Nose
This document is controlled while it remains on the Jabiru server. Once this no longer applies the document becomes uncontrolled.
ISSUE 1 2 3
Jabiru Aircraft
J120, J160, J170, J200/J400, J230/J430, J250/J450 Variants
544kg (category limitation)
Jabiru 53" pitch (1346mm)
Jabiru Scimitar 52" pitch
Figure 5 – J200 / J400 General Arrangement
4 5 Dated: 29th October 2014
Pty Ltd
J200
2
700kg
135 litres
3.5 litres
Jabiru 3300A
(1321mm)
500 x 6" rim
6" wide, 6 Ply
310 kPa (45 psi)
207 kPa (30 psi)
J400
4
700kg
135 litres
3.5 litres
Jabiru 3300A
Jabiru 53" pitch (1346mm)
Jabiru Scimitar 52" pitch
(1321mm)
500 x 6" rim
6" wide, 6 Ply
310 kPa (45 psi)
207 kPa (30 psi)
Issued By: AS Page: 26 of 298
