Figure 1 – J120-C General Arrangement - Jabiru j160 Technical Manual

Aircraft Technical Manual
JTM001-5
2.18.2 J120-C
Table 2-2 – J120-C Specifications
Model
Aircraft Maximum Weight
Fuel Capacity
Oil Capacity
Engine Model
Propeller Pitch
Nose Wheel Size
Main Wheel Size
Tyres Standard
Tyre Pressures Standard - Mains
Tyre Pressures Standard - Nose
This document is controlled while it remains on the Jabiru server. Once this no longer applies the document becomes uncontrolled.
ISSUE 1 2 3
Jabiru Aircraft
J120, J160, J170, J200/J400, J230/J430, J250/J450 Variants
Jabiru 42" pitch (1067mm)
Sensenich 43" pitch (1092mm) or
Sensenich 46" pitch (1168mm)
Jabiru Scimitar 38" pitch (965mm)
Figure 1 – J120-C General Arrangement
4 5 Dated: 29th October 2014
Pty Ltd
J120-C
500kg
(1102lb)
65 litres
2.3 litres
Jabiru 2200B
260 x 4" rim
400 x 4" rim
4" wide, 4 Ply
228 kPa (33 psi)
193 kPa (28 psi)
Other J120 Variants
500kg
(1102lb)
65 litres
2.3 litres
Jabiru 2200A
Jabiru 42" pitch (1117mm)
260 x 4" rim
400 x 4" rim
4" wide, 4 Ply
179 kPa (26 psi)
137 kPa (20 psi)
Issued By: AS Page: 22 of 298
