6.24 Fin (all J-Series)

The Fin is a moulded composite structure supported by ribs and a rear spar. Hinges attach the rear
spar to the rudder.
6.24.1 Removal, Installation, Inspection And Repair

The fin is an integral part of the fuselage structure and cannot be removed.

All repairs must be referred to Jabiru Aircraft Pty Ltd or our approved local agent.
6.25 Horizontal Stabiliser (all J-Series)

The horizontal stabiliser is a moulded stressed-skin structure of rigid cellular polystyrene bonded to a
fibreglass skin and rear spar.
6.25.1 Removal And Installation

The horizontal stabiliser is an integral part of the fuselage to which it is bonded. It cannot be
removed.

All repairs must be referred to Jabiru Aircraft Pty Ltd or our approved local representative.
