Aircraft Technical Manual
JTM001-5
Table 2-6 – J230/J430 Specifications
Model
Number of Seats
Aircraft Maximum Weight
Fuel Capacity
Oil Capacity
Engine Model
Propeller Pitch
Wheel Sizes Standard
Tyres Standard
Tyre Pressures Standard
- Mains
Tyre Pressures Standard
- Nose
This document is controlled while it remains on the Jabiru server. Once this no longer applies the document becomes uncontrolled.
ISSUE 1 2 3
Jabiru Aircraft
J120, J160, J170, J200/J400, J230/J430, J250/J450 Variants
J230-C, J230-D
135 litres
3.5 litres
Jabiru 3300A
Jabiru 53" pitch (1346mm) or
Jabiru 55" pitch (1397mm) or
Sensenich 53" pitch (1346mm) or
Sensenich 55" pitch (1397mm) or
Sensenich 56" pitch (1422mm)
Jabiru Scimitar 52" pitch
(1321mm)
500 x 6" rim
6" wide, 6 Ply
310 kPa (45 psi)
207 kPa (30 psi)
Figure 6 – J230 / J430 General Arrangement
4 5 Dated: 29th October 2014
Pty Ltd
2
600kg
Other J230
Variants
2
700kg
544kg (category
limitation)
135 litres
3.5 litres
Jabiru 3300A
Jabiru 53" pitch Jabiru 53" pitch
(1346mm) or
Jabiru 55" pitch Jabiru 55" pitch
(1397mm)
500 x 6" rim
6" wide, 6 Ply 6" wide, 6 Ply
310 kPa (45 psi) 310 kPa (45 psi)
207 kPa (30 psi) 207 kPa (30 psi)
Issued By: AS
J430
4
700kg
135 litres
3.5 litres
Jabiru 3300A
(1346mm) or
(1397mm)
500 x 6" rim
Page: 27 of 298
