Aircraft Technical Manual
JTM001-5
2.14

Equipment List

All possible combinations of equipment included in individual aircraft cannot be stated for reasons of
physical space. Table 2-1 provides a list of the typical equipment found in Jabiru J-series Aircraft.
Table 2-1 - Typical Equipment List
Aircraft
Engine
Propeller
Special Purpose
Compasses
Instruments
Pressure Gauges
Thermometers
Indicators
Lights
Radio
Fluid Quantity
Other
This document is controlled while it remains on the Jabiru server. Once this no longer applies the document becomes uncontrolled.
ISSUE 1 2 3
Jabiru Aircraft
J120, J160, J170, J200/J400, J230/J430, J250/J450 Variants
J120/J120-C/J160/J160-
D/J170/J170-C/J170-D
2200B (for factory built)
2200A (for all other)
Jabiru Wooden
Sensenich
Jabiru Scimitar
Toolkit
Magnetic
Altimeter
EFIS (Dynon D10A or D100 are typical)
EMS (Dynon D10 is typical)
EFIS/EMS (Dynon FlightDEK D180)
GPS (Garmin GPSmap296 or Aera 500 are typical)
Voltage meter
Engine Oil Pressure (analogue, part of EMS display)
Engine Oil Temperature (analogue, part of EMS display)
Engine Manifold Pressure (part of EMS display)
Engine Cylinder Head Temperature (analogue, part of EMS display)
Engine Exhaust Gas Temperature (part of EMS display)
Outside Air Temp (part of EFIS display)
Airspeed (analogue, part of EFIS display)
Tachometer (analogue, part of EMS display)
Engine hours (incorporated into Tacho or EMS)
Stall Warning
Trim indicator
Turn Coordinator (Electric, part of EFIS display)
Balance ball (analogue, part of EFIS display)
Vertical Speed (analogue, part of EFIS display)
Flap position
Anti Collision Strobe (fin and/or wingtip mounted)
Landing lights
Beacon
Interior
VHF Tx/Rx (1x or 2x microair M760 is typical)
XPNDR (microair T200SFL is typical)
Intercom (PM1000 is typical)
UHF Tx/Rx
Headsets
Oil Lubricant – 2.3 litres
Cabin Heater
Wheels Spats
Cargo Restraint
Three point personal harness
4 5
Pty Ltd
J200/J400/J230/J230-
C/J230-D/J430/J250/J450
3300A
3300L (Jab USA 230-D)
Jabiru Wooden
Sensenich
Jabiru Scimitar
Oil Lubricant – 3.3 litres
Dated: 29th October 2014
J160-C
2200C
Jabiru Wooden
Oil Lubricant – 2.3 litres
Issued By: AS Page: 19 of 298
