The calliper mount plate can be damaged by repeated bending, sharp bending or tool marks.
6.48 Brake Disc Wear Limit (all J-Series)
Measure the thickness of the brake disc in an area where it is not being worn – i.e. on one of the
1.
hub legs. Compare this measurement to the wear face of the disc. The maximum wear (i.e.
difference between the two measurements) is 2.0mm.
2. If brake disc is below minimum thickness, install a new part. For directional brake discs, refer to
Figure 70 for installation details.
6.49

Trouble Shooting - Brakes

Table 0-3 – Trouble Shooting – Brakes
Trouble
Dragging brakes
Brakes fail to operate
