17. ELECTRICAL SYSTEM
Maintenance Data
Operational precaution
●
When remove the battery, the disconnection sequence of cable terminals shall be strictly observed.
(First disconnect the negative cable terminal, next, the positive cable terminal.)
●
The model of the spark plug and the tightening torque.
● The ignition timing.
●
Adjustment of headlight.
●
Removal and installation of AC generator.
●
The maintenance free battery requires no inspection of electrolyte level and refilling of distilled water.
●
To recharge the battery, remove the battery from rack without removing ventilation caps.
●
Unless in emergency, never rapid charge the battery.
●
The voltage must be checked with the voltmeter while charging the battery.
●
As C.D.I assembly does not require an ignition timing check. In case ignition timing is incorrect, check
C.D.I and AC generator. Verify with an ignition timing light after replacement if necessary.

Technical Specification

Charging system

Battery
Leak current
Charging current
Control voltage in charging

Ignition system

Spark plug
Ignition coil and
resistance
Ignition timing
17-2
PDF created with pdfFactory Pro trial version
To this chapter contents
Description
Capacity
Charging rate
Description
Model
Gap
Primary winding
Secondary winding
"F" mark
www.pdffactory.com
Specification
12V12Ah
1.4A / 5 ~ 10 hours (standard)
14A / 0.5 hour (fast charging)
< 1mA
1.2 A / 1500rpm
14.5 + 0.5 V / 1500rpm
Specification
NGK CR8E (Recommended)
0.8mm
0.17 ± 10%Ω
Without cap: 3.1 ± 10KΩ
With cap:8.1 ± 10KΩ
10° TDC / 1700rpm
27°TDC / 4000rpm
